TR600 TAIL TORQUE TUBE UNIT H60252T

Instruction:

- Brand new tail gear box with higher material quality and easy maintenance.

- Utilizes dual point attachment design for zero play and higher precision control feel.

- Constructed with CNC aluminum alloy, with precision ball bearing at moving points, improving structure rigidity and smoothness, allowing rudder control to be more precise and smooth.

- 6061-T6 Aluminum alloy material and CNC processed.

- Suitable for T-REX 550/600.

Specification:

- Metal plate(L) x 1

- Metal plate(R) x 1

- Tail unit set x 1

- Tail rotor shaft assembly set x 1

- Bearing MR105ZZ x 2(Φ5xΦ10x4mm)

- Bearing 6701ZZ x 2(Φ12xΦ18x4mm)

- Socket screw x 4(M3x6mm)

- Socket screw x 1(M3x20mm)

- Vertical stabolizer mount x 1

- Socket collar screw x 2(M3x22mm)

- M3 Specialty washer x 2(Φ3xΦ8x2mm)

- Collar x 1(Φ12.4xΦ18x10mm)

- I-shaped Arm x 1

- Mount Link x 1

- Bearing holder x 1(13.5x12.5x9.5mm )

- Linkage ball A(M2x3.5) x 1(Φ4.75x8.18mm)

- Tail control arm x 1

- Bearing holder x 1(Φ7x Φ8.3x3.5mm)

- Bearing F682XZZ x 6(Φ2.5xΦ7.1xΦ2.6mm)

- Bearing MR117ZZ x 2(Φ7xΦ11xΦ3mm)

- Socket button head screw x 1(M3x5mm)

- Socket button head screw x 6(M2.5x5mm)

- Slider Shaft x 1(Φ8x7x17.6)
