RADIO 6CH T6EHP HELIC 2.4GHZ RADIO LINK

Digital 2.4GHz 6-Channel Transmitter (T6EHP)

Digital 2.4GHz 6-Channel RC system T6EHP adopted FHSS 2.4GHz technology, it is applied for 3D helicopter. Owing to the most advanced 2.4GHz radio control technology, it is needless to fit crystals for both transmitter and receiver, meanwhile RC system can avoid the interaction problem best up to the advanced code matching mechanism.

Standard Programming Functions:

Model Select six model memory.

Model Type helicopter programming. (for airplane is another version)

Servo Reversing on all six channels.

Dual Rate/Exponential for ailerons, elevator and rudder.

End Point Adjustment fine-tunes servo throws on all six channels.

Digital Trim stores trim settings for each model for aileron, elevator, rudder and throttle.

Fail Safe a safety throttle setting in case of loss of transmitter signal.

Battery Fail Safe moves the throttle to a preset position when the airborne pack reaches 3.8V.

Stick Mode choose from Mode 1 through 4.

Range Checking Power Down reduces transmitter output power for up to one minute, allowing range checking from 50 paces away.

Changeable Throttle Stick select ratchet for airplanes or smooth for helis.

Adjustable Stick Length choose the length that suits your flying style.

Helicopter Specific Programming Functions:

5-Point Normal and Idle Up Throttle/Pitch Curves.

Throttle Hold for autorotation.

Revo (Revolution Mixing) mixes rudder and pitch together.

Gyro Mixing two gyro gain settings can be programmed and selected during flight.

Swash to Throttle Mixing corrects slowing of the engine's speed caused by the swashplate.

Swashplate Types choose from 1S (independent aileron, pitch and elevator servos linked to the swashplate), 3S (120° CCPM), or 3E (90° CCPM).

Swash AFR Adjustable Function Rate, for use with 1S, 3S or 3E swash types
