TR450 SPORT 3G FLYBARLESS SYSTEM H45109
- Código: 52108
- Marca: ALIGN
- Estoque: Disponível
-
$99,00
Não fazemos entregas fora do paraguai
Preços informados são em Dólares americanos, não incluem IVA e podem variar sem prévio aviso.
| Instruction: | Specification: |
|
- Use for T-REX450 series(PRO/SPORT/SE V2/SE)ÂB - 3-axis gyroscopic flybarless system to simulate the stability of mechanical flybar system, yet at the same time achieving agile 3D performance. - Utilizes Silicon Micro Machine (SMM) sensors for excellent stability. - 12 bit processors providing ultra high resolution, resulting in highly precise controls - Software upgradable through PC interface adapter (sold separately) - Simplistic setup process without the need of external devices. Setup is done through 5 steps and 2 sensitivity adjustments. Rudder setup is identical to GP780 gyro, minimizing learning curve. - Flybarless system dramatically improves 3D power output and efficiency, resulting in reduced fuel or electricity consumption. - Highly sensitive gyroscopic sensors combined with advanced control detection routine providing higher hovering and aerobatic stability than other flybarless system. - Suitable for all CCPM and mechanical mixing system. - Comaptible with helicopter of all sizes from T-Rex 250 to T-Rex 700. - Innovative Pitch Gau as an aid to facilitate pitch adjustments. - High frame rate signal output for faster and higher precision servo response. - Capable to operate between 3V to 8.4V, compatible with high voltage servos. - Small footprint, light weight, minimalists and reliable design. |
- Suitable Voltage Range:DC 3V~8.4V - Current Comsumption:<80mA @ 4.8V - Flip and Roll rate detection speed: :±300degrees/sec - Rudder rate detection speed:±500degrees/sec - Sensor resolution: 12bit - Operating temperatur:-20ÂŽ~65ÂŽ - Operating humidity:0%~95% - RoHS certified - Dimension: Control box:42x26.5x14.5mm Sensor:22.3x21.7x14mm -Weight: Control box:16g Sensor:9g |
| Accessories: | |
|
- Main Rotor head Set x1 - Flybarless control unit x1 - Flybarless Sensor x1 - Screw bag x1 - Linkage rod A x2 - Linkage ball A x2 - Head Stopper x1 - Mixing base assembly x1 - Pitch Gauge x1 - Sensor mounting foam x2 -Signal extension wire 100mm x1 |
