CABO "Y" FUTABA J-TYPE AEC16 FUTM4135

This is a Futaba J-Series Dual Heavy Duty Extension.

This extension comes from the receiver and allows two servos to be connected for dual aileron servo applications. On one end of the wire is a male connector, the other end has two female connectors.

The female connectors are molded together unlike a Y-harness that splits apart.

FEATURES:

Connectors slide snugly together to guard against vibrating loose.

Gold-plated terminals improve conductivity and prevent oxidation for longer lifespan.

Heavier, 20-gauge wire handles higher current loads with ease.

Functions with standard or digital servos

INCLUDES:

One Futaba J-Series Dual Heavy Duty Extension

SPECS:

Wire Gauge: 20

Wire Length: 6" (152mm)

Wire Color Codes-

Black: negative

Red:   positive

White: signal (polarity tab is on the signal side)
