AVIAO PILOT RC DECATHLON 107" (2.70M) DE-09

AVIAO PILOT RC DECATHLON 107

 Features:

• Strong yet light weight design, good for acrobatic  flying and can even hover!
• Fast to put together at the field
• Highly prefabricated, experienced builders can have air ready in under a day
• Pre-installed hinges (glued and pinned)
• Internally mounted cowling – so no external screws exposed
• Removable wings and stabs
• Laser engraved motor mounting position and multiple servo locations available for Rudder setup (pull pull or direct push pull)
• Optional LED Light Set

Included hardware:

• Complete air frame with all basic accessories (such as carbon fibre main undercarriage, tail-gear assembly and wing-tubes as well as fibreglass control horns and wheel pants)
• Pre-installed hinges and pre-mounted canopy
• Fuel tank and fuel tubing pre-prepared, fuel dot and breather valve
• Wheels, axels and wheel pants
• Pre-preared pull-pull wires and pushrods with ball links
• Matching carbon spinner, 3.5″

Required hardware:

• Motor: 30-60cc or equivalent electric
• Servos: 7-8 high torque (minimum 20kg) plus throttle // Uses x1 per aileron, x1 per flap, x1 per elevator and x1 or x2 on rudder
• Also requires all the usual accessories such as transmitter, receiver, propeller, batteries, powerbox, extension leads and possibly other small accessories.

Pilot-Rc recommended hardware:

• Servos: Pilot-Rc PW28AH (28Kg – 0,056s at 8,4v)
• Servo arms: Pilot-Rc 1,6″ Aluminium arms (included with Pilot-Rc servos)
• Lighting: Pilot-RC LED Light set for Decathlon with programmer

Specifications:
