AVIAO PILOT RC DECATHLON 150" (3.81M) DE-CH3

Decathlon – 150″ (3.81m)

If you are looking for a big plane that runs on a small engine and can still do all the tricks while still being stable, forgiving and even relaxing… You need a Decathlon!

Colour scheme DE-CH3:

References: Oracover 21-010, 21-050, 21-023 / Ultracote HANU870, HANU873, HANU89*

SPECIFICATIONS:

• Model: Decathlon – 40%
• Wingspan: 150″ (3.810mm)
• Length: 102″ (2.580mm)
• Wing area: 3,758 “² (24,245 cm²)
• Weight: 39.24lbs (17.8kg)

FEATURES:

• Strong yet light weight design, good for acrobatic flying and can even hover!
• Genuine German Oracover (Ultracote) covering
• Fast to put together at the field
• Highly prefabricated, experienced builders can have air ready in under a day
• Pre-installed hinges (glued and pinned)
• Internally mounted cowling – so no external screws exposed
• Removable rudder (as well as removable wings and stabs)
• Laser engraved motor mounting position and multiple servo locations available for Rudder setup (pull pull or direct push pull)
• Optional LED Light Set

INCLUDED HARDWARE:

• Complete air frame with all basic accessories (such as carbon fibre main undercarriage, tail-gear assembly and wing-tubes as well as fibreglass control horns and wheel pants)
• Pre-installed hinges and pre-mounted canopy
• Fuel tank and fuel tubing pre-prepared, fuel dot and breather valve
• Wheels, axels and wheel pants
• Pre-preared pull-pull wires and pushrods with ball links
• Matching carbon spinner, 5″

REQUIRED HARDWARE:

• Motor: 80-120cc or equivalent electric
• Servos: 10 high torque (minimum 20kg) plus throttle // Uses x2 per aileron, x1 per flap, x1 per elevator and x2 on rudder
• Also requires all the usual accessories such as transmitter, receiver, propeller, batteries, powerbox, extension leads and possibly other small accessories.

PILOT-RC RECOMMENDED HARDWARE:

• Servos: Pilot-Rc PW28AH (28Kg – 0,056s at 8,4v)
• Servo arms: Pilot-Rc 1,6″ Aluminium arms (included with Pilot-Rc servos)
• Lighting: Pilot-RC LED Light set for Decathlon with programmer
