TURBINA KINGTECH K-130G4+ KERO START

• KingTech G4 utilizes SBus data transmission.
• Engine/ECU integration, all operating parameters including total run time are all recorded into the engine.
• The smaller and lighter external Data Relay Module (DRM) is responsible for all data, signal and power transmission.
• Pump: digital sbus brushless pump
• A micro USB connector is present for a future connectivity of wireless mobile apps.
• The G4 features a brushless starter motor for reliability and durability, built-in FOD screen is also integrated.
• After a run cycle and receiver switched off, GSU will remain on only until cool down completes.

K-130G4 SPECIFICATIONS

• Diameter: 94.5mm ( 3.72" )
• Length: 220mm ( 8.66" )
• Weight: 1200g ( 2.64lb ), include mount 1270g ( 2.79lb )
• Max. RPM: 142000
• Thrust: 13kg @ 15° C ( 28.6lb @ 59°F )
• EGT: 700°C
• Fuel consumption: 410g / min ( 14.46 / min )
• Fuel: Diesel, Jet A1, Kerosene
• Lubrication: 5%



G4 MODEL COMPONENTS LIST

• Engine
• Data Relay Module (DRM)
• Ground Support Unit (GSU)
• Wire Harness and Tubing Set
• Fuel Pump, Filter and Shout-off Valve
• Fuel Inlet Attachments
• Instruction Manual
