JETI POWER MAIN SWITCH 100A WITH R3/RSW WIRELESS JETIMSW100R3

Power Switch	Main Switch 100A
Type	Main Power Switch
Max Input Voltage	51V
Min Input Voltage	9V
Current Consumption	20mAh
Output Current	100A Continues
Dimensions	80mm x 36mm x 25mm
Weight	110g
Applications	On/Off Switch w/Telemetry

Main Switch is an electronic primary switch designed for switching of the main power supply (Main Battery) for your RC model. It adds an element of safety when handling the model, without the need to physically disconnection of the main battery pack. The advantage of an electronic switch is that it offers a virtual unlimited On/Off cycles, unlike mechanically operated switches. The Main Switch prevents the connectors from sparking when connecting the batteries, in fact it also replaces Anti-Spark connectors.

The Main Switch 100 and 200 are shipped with a magnetic or R3/RSW receiver/wireless switch. The Main Switch is primarily designed for switching the main battery of the RC model, but can also be used in applications where switching a DC power supply is needed.

The Main Switch comes equipped with complete Jeti telemetry. It measure Voltage, Current, Battery Capacity, and Temperature. Alarms can be set to monitor maximum current, minimum voltage, battery used capacity, and maximum temperature.
