IMAX CHARGER B6 NANO CHARGE/DICHARGER SK-100134

Description

All-new from SkyRC is the B6 Nano 320W DC micro multi-chemistry charger. It measures a compact 76x85x37mm and weighs in at only 130g but packs a bunch of features such as a 2-inch black screen display, touch buttons, up to 15A charging current, and 6S LiPo-compatibility.

The easy to navigate interface makes it one of the fastest and easiest chargers to use. Even though its tiny, this thing packs a punch and can charge up to 15A / 320W!

It is equipped with Bluetooth to support charging from the SkyRC App on your smartphone! Set parameters for charging, save profiles, and monitor your batteries from a distance or even update your firmware from your phone as well!

To take advantage of B6 nano’s full power capability, the power source should be 9-32V DC, and output power should be capable of 380W or higher.

Features

• Tiny charger - 76x85x37mm
• Large screen (50x37.5mm) to display essential information without complex menus
• Capacitive touch buttons
• Refined user-friendly interface
• Up to 320W charging power (with official 320W power supply)
• ARM® Cortex®-M4F 32 bits high-speed processor using industry-leading 2.5V-5.5V wide range input voltage

Specifications

• Input Voltage: DC9-32V
• Max Charge Power: 320W
• Max Discharge Power: 5W
• Charge Current Range: 0.1-15.0A
• Discharge Current Range: 0.1-3.0A
• LiPo/LiFe/Lilon/LiHV Cells: 1-6S
• NiMH/NiCd: 1-15S
• Pb Battery Voltage: 2-20V
• Net Weight: 130g
• Dimension: 76x85x37mm

Includes

• 1x B6 Nano Charger
• 1x XT-60 Male to Female Cable
