Ready for your off-road experience?
Experience the versatility and advanced design of the Gelande 2. It’s packed full of capability to take on and conquer any challenge. Put your driving to the test and see the G2 conquer with ease. It’s built for versatility and durability and completely customizable. Start hitting trails right out of the box, everything is included! Charge up, and roar out to your adventure!
- Cast metal axles with locked differentials
- Custom designed for true to scale looks
- Twister high torque metal gear digital servo
- Chassis mounted steering servo
- 540 Crawler brushed 45T motor
- 3-Link front and 4-link rear suspension
- Super grip dirt grabber tires
- R3 single speed transmission
- Realistic aluminum ladder frame chassis
- Center-mounted realistic 4x4 transfer case
- Outcry II waterproof ESC
FEATURES
- Chassis: Machined billet aluminum ladder frame, steering servo mount on chassis
- Drive: Four wheel, plastic shaft for wide driveline angles and durability, steel universals, center mounted 4x4 transfer case
- Axles: Cast Yota II Ratio: 15/40 = 2.67:1, width at hex 7.1" (180.5mm), 8° round knuckles, removable diff covers, lower mounting points
- Transmision: R3 Single speed, wide 32P steel gears, with slipper clutch, 14/64 = 4.57:1 internal ratio 1.78:1
- Transfer Case: Wide 32P hardened steel gears, eight ball bearings, cast metal casing, ratio: 1.47:1
- Motor: 540 size brush equipped 45 turn crawler
- Radio: XR-3 3 channel 2.4GHz, 3rd channel can be used to control an optional winch (not included)
- Steering Servo: Twister metal gear digital with 153oz/in of torque at 6V, full metal gear drivetrain
- Electronic Speed Control: Outcry waterproof with built-in drag brake and separate 6V 5amp turbo BEC, Standard battery connector
- Spur Gear: Delrin construction, 64 teeth
- Axles: Cast metal with locked differentials
- Motor Mount: Billet aluminum
- Suspension: G2, double triangulated 4 Link rear suspension, 3 link front suspension with panhard bar
- Shocks: Billet aluminum, dual spring 80mm, can be oil-filled
- Body: Molded hard plastic in forest green with white roof, over 70 separate parts including interior, seats, gearshift, handbrake, dashboard, metal grille insert with lenses for all signal lights, lights can be illuminated with optional LED light kit, separate purchase
- Battery: 6-cell 3000mAh NiMH
- Battery Charger: 110V AC wall charger
- Receiver Box: Plastic fuel cell type
- Wheels: Stamped steel beadlock design with black finish 1.9" (48mm) diameter 0.98" (25mm) wide, 0.43" (11mm) back spacing
- Tires: Super grip Dirt Grabber X3 compound with foam inserts
- Bumpers: Front and rear, constructed of machined billet aluminum
- Warranty: RC4WD warrants the product to be free from defects when new. Limited warranty does not cover damages due to normal wear and tear, user error of assembly or installation, user modifications, user's failure to perform routine maintenenace and addition of aftermarket parts or optional parts.
INCLUDES
- RTR Gelande II Truck with Cruiser Body, Body Trim, Interior, 3-ch 2.4GHz Radio, Outcry ESC, 45T Motor, Tires, Wheels, Decals,
- Battery, Battery Charger and Instruction Manual
REQUIREMENTS
- AA Batteries: Eight for transmitter
- Building and track equipment
SPECIFICATIONS
Vehicle:
- Wheelbase: 10.8" (275mm)
- Length: 18.3" (466mm)
- Width: 8.7" (220mm)
- Height: 10" (254mm)
- Ground Clearance: 2.2" (55mm)
- Final Drive Ratio: 31.9:1
- Weight: 7.08lbs / 3.21kg
Body:
- Length: 16.42" (416mm)
- Width: 7.52" (191mm)
- Height: 6.54" (166mm)
- Weight: 26.31oz (746g)
- Wheelbase: 11.10" (282mm)
COMMENTS
Transmission and axles are preassembled, and the manufacturer does not state the size of ball bearings used in each component.
