RC4WD GELANDE II 1/18 D90 BLUE Z-RTR0039

Experience the versatility and advanced design of the 1/18 Gelande II for yourself.

Packed full of capability, the Gelande II is ready for any challenging condition. Put your off-road driving to the test and see why the G2 is unmatched in its class!

The G2 is built with quality materials and craftsmanship. It can maneuver extreme descents and climbs with ease. The new 1/18 Mini Transmission provides power to the 1/18 Yota II Axles.

The core of the G2 is built for the true off-road enthusiast. From emergency and expedition vehicles, down and dirty off-road rigs and even daily drivers, the G2 can be customized to pull off any look you choose. The G2 delivers on performance and looks to match the drivers identity.

The G2 comes with double triangulated 4 Link Front and Rear Suspension. The servo is mounted on the chassis out of view for a more scale appearance.

What's Included:

• 1x RC4WD 1/18 Gelande II RTR w/D90 Body Set (Blue)

Are you ready for your off-road experience?

• Custom Designed For True To Scale Looks
• Realistic Aluminum Ladder Frame Chassis
• R5 1/18 Mini Transmission V2
• 1/18 Cast Front and Rear Axle Set
• 4 Link Front and 4 Link Rear Suspension
• Dirt Grabber 1.0" All Terrain Tires
• Stamped Steel 1.0" Stock Beadlock Wheels (White)
• 9G Analog Metal Gear Micro Servo
• The Ultimate Mini Scale Shocks (40mm)

All New R5 1/18 Mini Transmission V2

• Total Gear Ratio: 5.5 : 1
• Pinion Gear: 55P 10T
• Gear Material: Hardened Brass and Steel
• Case Material: Plastic Injection Molded

All New 1/18 Cast Yota II Axles

• Ratio: 2.55 : 1
• Width at Hex : 92mm
• Case Material: Zinc Alloy

G2 Suspension

Double Triangulated 4 Link Front and Rear Suspension

Shock Absorbers

Ultimate 40mm Scale Shocks - Can not be Oil Filled

Wheels

• Type: 1.0" 6 Lug Beadlock Wheels
• Hub: 7mm Hex
• Width: 7mm
  Back Spacing: 7mm

Bumpers

Machined Billet Aluminum, Light Weight

G2 Truck Dimensions

• Wheelbase: 130.75mm (5.15")
• Width: 108.08mm (4.26")
• Height: 120.53mm (4.75")
• Ground Clearance: 30.74mm (1.21")
• Final Drive Ratio: 112 : 1
• Weight: 1.87lbs / 0.85kg

SUSPENSION

• The G2 Chassis features a simple front mounted electronics plate for easy mounting of the XR2 Micro ESC/Receiver combo.
• The G2 includes a set of RC4WD Micro Ultimate Scale Shocks. Designed for ultimate scale looks and ultimate performance. The shocks are machined from billet aluminum and internally sprung.
• The G2 Chassis is a machined billet aluminum ladder frame with a 4 link suspension design, scale shock hoops, chassis servo mounts and hard body mounting points for the ultimate in strength.
• The G2 includes a set of RC4WD White Stamped Steel 1.0'' Stock Beadlock Wheels. These feature a super tough white finish, aluminum internal locking ring and popular 6 lug design.
• Every G2 needs a tough set or rock grabbing tires and the included Dirt Grabbers in our advanced X3 soft compound deliver the traction you need as well as perfect scale looks in just the right size.

DETAILS

• The G2 features the D90 Scale Body Set. The D90 body has an awesome assortment of scale details including chrome decals for the mirrors, door handles, vents and detailed grille to match the 1:1 vehicle.
• The unmistakable lines of a classic. The D90 Body Set is an exact replica of the fully scale vehicle, right down to the rivets! No other scale body comes this close to realism.
• The D90 Body Set comes in durable, molded hard plastic that is professionally painted in Blue for a simple, but impressive look.
• The D90 Body Set features a full detailed interior including steering wheel, seats, gear shifter, handbrake and a detailed dashboard. It's all here to bring your build to next level.
• The crisp lines and subtle details are all captured. Detailed parts are included as well as clear lenses for all signal lights.

DRIVETRAIN

• The 1/18 G2 includes a quality 2-in-1 Micro ESC + Receiver paired with the XR2 Micro Radio system and is ready for your next scale adventure!
• The G2 includes the new R5 1/18 Mini Transmission V2. Packed with scale detail, the R5 features a high quality plastic exterior and heavy duty gears for durability.
• The Driveshafts for the G2 feature bulletproof steel universals and a new high quality steel shaft for great driveline angles and durability on the trail.
• The most scale accurate axles on the market, the RC4WD 1/18 Cast Yota II Axles feature innovative 8 degree round knuckles, unique removable diff covers, new lower mounting points and a compact offset pumpkin in the front.
• It's ALL in the box! Everything you need is provided to get you on the trails today!
