IMAX CHARGER S60 AC BALANCE CHARGER SK-100106-02

Description:

SkyRC S60 AC Professional Charger/Discharger stands out for its exquisite and stylish design. It can charge nearly all current battery types in the market, including new generation LiPo battery with end voltage 4.35V. What's more, users could set the terminal voltage by themselves and connect it to PC for PC control and firmware upgrade. Besides that, users could also use it as Lithium Battery Meter and Battery Internal Resistance Meter.

Specifications:

• Dimensions: 112 x 106 x 52 mm
• Net Weight: 310g
• Input Voltage: AC100-240V
• Charge Circuit Power: Max. 60W
• Discharge Circuit Power: 10W
• Charge Current Range: 0.1-6A
• Discharge Current Range: 0.1-2A
• Current Drian for Balancing Port: Max 200mA/cell
• Trickle Charging Current: 50mA-300mA & OFF
• LiPo/LiFe/Lilon/LiHV Battery Cell Count: 2-4S
• NiMH/NiCd Battery Cell Count: 6-8S
• Pb Battery Voltage: 6-12V

Included:

• SKYRC S60 Charger
• Power Cord
• 18AWG Charging Cable with XT60 Connector

S60 Charger

AC Power Cord

XT60 Charging Cable

Instruction Manual
