DJI RTF PHANTOM 4 ADVANCED S/TELA

MAIN FEATURES:

• 20MP 1 inch CMOS camera, 4K 60fps fluent video shooting and up to 14fps Burst Mode, H.264 and H.265 video coding at 100Mbps
• A mechanical shutter is used to eliminate distortion when taking images of fast moving objects or flying at a high speed
• Advanced FlightAutonomy system made up of 5 vision sensors, GPS and GLONASS, ultrasonic rangefinder and redundant sensors
• Up to 4.3 mi. ( 7km ) super long image transmission range, 2.4GHz ISM working frequency and 220ms low latency, 720P 30fps Live View
• More reliable and steady flight thanks to the dual compass modules, dual IMU units and state-of-the-art algorithm to process data
• 30 minutes' flying and outstanding BMS for extended battery lifetime; rigid titanium alloy and magnesium alloy airframe, even lighter than Phantom 4
• Intelligent flight with optimized Waypoints ( Draw ), ActiveTrack, TapFly, Return to Home as well as Gesture Mode for taking selfies at a distance

SPECIFICATIONS:

• AIRCRAFTWeight: 1368g ( including battery and propellers )
• Diagonal size: 350mm ( excluding propellers )
• Max. ascent speed: S-mode: 6m/s; P-mode: 5m/s
• Max. descent speed: S-mode: 4m/s; P-mode: 3m/s
• Max. speed: S-mode: 45 mph ( 72 kph ); A-mode: 36 mph ( 58 kph ); P-mode: 31 mph ( 50 kph )
• Max. tilt angle: S-mode: 42 degree; A-mode: 35 degree; P-mode: 25 degree
• Max. angular speed: S-mode: 250 degree/s; A-mode: 150 degree/s
• Max. service ceiling above sea level: 19685 feet ( 6000m )
• Max. wind speed resistance: 10m/s
• Max. flight time: approx. 30 minutes
• Operating temperature range: 32 to 104 Deg.F ( 0 to 40 Deg.C )
• Satellite positioning system: GPS / GLONASS
• Hover accuracy range: vertical: + / - 0.1m ( with Vision Positioning ); + / - 0.5m ( with GPS Positioning ); horizontal: + / - 0.3m ( with Vision Positioning ); + / - 1.5m ( with GPS Positioning )

VISION POSITIONING

• Vision system: Forward Vision System, Downward Vision System
• Velocity range: 31 mph ( 50 kph ) or less at 6.6ft ( 2m ) above ground
• Altitude range: 0 - 33 feet ( 0 - 10m )
• Operating range: 0 - 33 feet ( 0 - 10m )
• Obstacle sensory range: 2 - 98 feet ( 0.7 - 30m )
• FOV: forward: 60 degree ( horizontal ), + / - 27 degree ( vertical ); downward: 70 degree ( front and rear ), 50 degree ( left and right )
• Measuring frequency: forward: 10Hz, downward: 20Hz
• Operating environment: surface with clear pattern and adequate lighting ( more than 15 lux )

TRANSMITTER

• Operating frequency: 2.400 - 2.483GHz
• Max. transmission distance: FCC: 4.3 mi. ( 7km ); CE: 2.2 mi. ( 3.5km ); SRRC: 2.5 mi. ( 4km )
• Operating temperature range: 32 to 104 Deg.F ( 0 to 40 Deg.C )
• Battery: 6000mAh 2S LiPo
• Transmitter power ( EIRP ): FCC: 26dBm; CE: 17dBm; SRRC: 20dBm
• Operating current / voltage: 1.2A at 7.4V
• Video output port: GL300C: USB
• Mobile device holder: GL300C: for tablets ans smart phones ( not included )

INTELLIGENT FLIGHT BATTERY

• Capacity: 5870mAh
• Voltage: 15.2V
• Battery type: 4S LiPo
• Energy: 89.2Wh
• Net weight: 468g
• Charging temperature range: 41 to 104 Deg.F ( 5 to 40 Deg.C )
• Max. Charging power: 100W

GIMBAL

• Stabilization: 3-axis ( pitch, roll, yaw )
• Controllable range: pitch: -90 to +30 degree
• Max. controllable angular speed: pitch: 90 degree/s
• Angular control accuracy: + / - 0.02 degree

CAMERA

• Sensor: 1 inch CMOS, effective pixels: 20MP
• Lens: 84-degree FOV 8.8mm / 24mm ( 35mm format equivalent ) f/2.8 - f1.1 auto focus at 1m to infinity
• ISO range: video: 100 - 3200 ( auto ), 100 - 6400 ( manual ); photo: 100 - 3200 ( auto ); 100 - 128000 ( manual )
• Mechanical shutter speed: 8 - 1/2000s
• Electronic shutter speed: 8 - 1/8000s
• Image size: 3:2 aspect ratio: 5472 x 3648; 4:3 aspect ratio: 4864 x 3648; 16:9 aspect ratio: 5472 x 3078
• PIV image size: 4096 x 2160; 3840 x 2160; 2720 x 1530; 1920 x 1080; 1280 x 720
• Still photography modes: Single Shot; Burst Shooting: 3 / 5 / 7 / 10 / 14 frames; Auto Exposure Bracketing ( AEB ): 3 / 5 bracketed frames at 0.7 EV Bias
• Interval: 2 / 3 / 5 / 7 / 10 / 15 / 20 / 30 / 60s
• Video recording modes: H.265; H.264; C4K: 4094 x 2160; 4K: 3840 x 2160; 2.7K: 2720 x 1530; FHD: 1920 x 1080; HD: 1280 x 720
• Max. video bitrate: 100Mbps
• Supported file system: FAT32 ( 32GB or less ); exFAT ( more than 32GB )
• Photo: JPEG, DNG ( RAW ), JPEG + DNG
• Video: MP4 / MOV ( AVC/H.264, HEVC/H.265 )
• Supported micro SD card: max. capacity: 128GB; write speed: 15MB/s or more, Class 10 or UHS-1 rating
• Operating temperature range: 32 to 104 Deg.F ( 0 to 40 Deg.C )

CHARGER

• Voltage: 17.5V
• Rated power: 100W

APP / LIVE VIEW

• Mobile app: DJI GO 4
• Live View working frequency: 2.4GHz ISM
• Live View quality: 720P at 30fps
• Latency: Phantom 4 Advanced: 220ms ( depending on condition and mobile device )
• Required operating system: iOS 9.0 or later, Android 4.4 or later
• App download: App Store, Google Play

General

Features: Brushless Version,Camera,Radio Control,WiFi APP Control,WiFi FPV
Functions: Automatic Return,Forward/backward,Hover,Sideward flight,Slow down,Speed up,Tap to Fly,Turn left/right,Up/down,Visual Tracking,Waypoints,WiFi Connection,With light
Size: Large
Satellite System: GLONASS,GPS
Diagonal Length: 350mm ( excluding propellers )
Max Speed: S-mode: 45 mph ( 72 kph ); A-mode: 36 mph ( 58 kph ); P-mode: 31 mph ( 50 kph )
Max Ascent Speed: S-mode: 6m/s; P-mode: 5m/s
Max Descent Speed: S-mode: 4m/s; P-mode: 3m/s
Hover Accuracy: + / - 0.1m ( with Vision Positioning ); + / - 0.5m ( with GPS Positioning ); horizontal: + / - 0.3m ( with Vision Positioning ); + / - 1.5m ( with GPS Positioning )
Built-in Gyro: 6 Axis Gyro
Kit Types: RTF
Level: Advanced Level

Connectivity

Remote Control: 2.4GHz Wireless Remote Control
Channel: Unknown
Radio Mode: Mode 2 (Left-hand Throttle)
Control Distance: 7km
Compatible with Additional Gimbal: Yes
FPV Distance: 7km
Transmitter Power: Built-in rechargeable battery
Model Power: Built-in rechargeable battery

Battery

Battery: 5870mAh 14.8V 4S LiPo
Flying Time: About 30mins
Battery Weight: 468g

Camera

Camera Pixels: 20MP
Video Resolution: C4K: 4094 x 2160; 4K: 3840 x 2160; 2.7K: 2720 x 1530; FHD: 1920 x 1080; HD: 1280 x 720

Package Contents

Package Contents:

1 x Aircraft Body ( Intelligent Flight Battery Included ),

1 x Transmitter, 8 x Propeller,

1 x Battery Charger,

1 x Power Cable,

1 x Set of English Manuals,

1 x Gimbal Clamp,

1 x USB OTG Module,

1 x Micro USB Cable,

1 x 16GB Micro SD Card,

1 x Carrying Case
