TR150X BRUSHLESS ESC HEG15003T

Product:

Package:

Instructions:Specification:

- Use for T-REX 150.
- Must with 150 GRS( HEG15002 )
- Manual Download：
●

- Main motor output current: Continuous 6A / Surge 7A
- Tail motor output current: Continuous 3A / Surge 3.5A
- BEC output current: Continuous 5V/2A / Surge 5V/2A
- Persistent maximum current require optimal heat dissipation condition.
- Supported motor types: 2 poles to 18 poles brushless outrunners.
- Maximum rotational speed: 2 poles-240000 RPM, 12 poles-40000 RPM.
- Input voltage: 2S Li-Po.Accessories:- 7A Brushless ESC x 1
- 150 GRS Double Sided Tape A x 1
- 150 GRS Double Sided Tape B x 1
- 150 Battery Socket x 1
- 150 Battery Socket Mount x 1
