RADIO 10CH ALIGN T10 AFHDS HERT1002T

Product:

Focus Shot1(T10 Transmitter)Focus Shot2(AR18i Receiver)Focus Shot3(Ni-MH chargeable battery AA)

Focus Shot4(Phone Screen Bracket/Monitor Mount)Focus Shot5(AR18i Signal Wire/Micro USB)Focus Shot6(User Guidance And Precautions)

Package:

ALIGN T10 Transmitter mode2 to mode1:

T10 Specification:AR18i Specification:●Channel: 10 channels

Model Type: Quadcopter

RF Range: 2.4055 ~ 2.475 GHz

RF: <20dBm

System Mode: 2.4G system AFHDS 2A

Power Input: 4.2V ~ 6.0V

Display: 73x39mm, LCD Backlight touch screen

Transmit Distance: In open space without interference <1000M

Antenna Length: 26mm(Dual Antenna)

Weight: 410g(not incloude battery)

Dimension: 179x81x161mm

Certificate: CE0678, FCC, NCC(CCAJ16LP2890T5)●Channel: 18 channels

RX Sensitivity: -105dBm

RF Range: 2.4055 ~ 2.475 GHz

System Mode: 2.4G system AFHDS 2A

Power: 4.0 ~ 6.5V DC

Transmit Distance: In open space without interference <1000M

Weight: 14.9g

Dimension: 27x26.2x15mm

Certificate: CE0678, FCC, NCC(CCAJ16LP3030T2) Instructions:Accessories:●AFHDS2A(Automatic Frequency Hopping Digital System Second Generation) features with superior protection against interference, low power consumption, and high sensitivity receiver.

Capacitive touch screen design makes setup much intuitive and simple.

Equipped with 4 switches, 2 knobs and 2 buttons for multi-functionality setup.

Support Mode 1, Mode 2, Mode 3, Mode 4 stick mode.

Independent identification ID enhance the system stability of proactive anti interference.

High efficiency Omni-directional gain antenna maintaining a strong reliable connection.

Optional mobile phone holder available for FPV screen viewing.

Feature with update function.

Feature with stick trim function.●T10 Transmitter x 1

Phone Screen Bracket x 1

Monitor Mount x 1

AR18i Receiver x 1

AR18i Signal Wire x 1

1.5V Ni-MH chargeable battery(AA size) x 4

Micro USB x 1

User Guidance x 1

Precautions x 1
