MR25 5.8G VIDEO TRANSMIT 600 HEDFVT04T

Product:

Mechanical Dimension:

Instruction:

- Suitable for MR25 / MR25P.

- Light, tiny and durable material.

- Long term, low-level noise.

- 40 channel including Raceband frequency allow to reduce signal interference in competitions.

- Support 25mW ~ 600mW power output.

- Easy to operate : Single easy-switch button and LED indicator.

- Compatible with vary receiver frequencies and FPV racing models.

- Memory Function : Recording previous flight channel and frequency in memory.

- Built-in microphone.

- Support 5V power output for FPV camera.

Specification:

- Operating Channels: 40 CH

- Input Voltage: 7 ~ 20V DC

- Operating Current: 100mA 12V(25mW), 300mA 12V(600mW)

- Antenna Interface: RP SMA

- Transmitting Power: 25mW ~ 600mW

- Dimesion: 34x25x12mm

- Weight: 10.6g(Exclude Antenna)

Content:

- 5.8GHz Video Transmitter Circuit Board x 1

- 5.8GHz Video Transmitter Canopy - Upper x 1

- 5.8GHz Video Transmitter Canopy - Lower x 1

- 5.8GHz Video Transmitter Wire Set x 1

- 5.8GHz Video Transmitter Sided Tape x 1
