IMAX CHARGER B8 ULTIMATE 1000WAT BL SK-100069-02

Description

SKYRC Ultimate 1000W features with high efficiency with synchronous rectification technology, it is accurate and stable and also has some new features and functions. Users could set the terminal voltage by themselves and connect it to PC for PC control and firmware upgrade. What's more, users could also use it as Lithium Battery Meter and Lithium Battery Internal Resistance Meter. There are Automatic Charging Current Limit, Capacity Limit, Temperature Threshold and Processing Time Limit which makes the charger safe to use.

Features:

Balance Port for Charging / Discharging

• For some small batteries without main connector, you could use the battery socket to charge and discharge the battery to storage status.

LiHV Mode Available

• The additional LiHV mode is able to charge the new generation of LiPo batteries with an end of charge voltage of 4.35 V.

Charge Master

• The user can monitor pack voltage, cell voltage and other data during the charging, view charge data in realtime graphs, and can also control charging and update firmware from "Charge Master".

Finally, Your Charger Gets Its Own App

• Smart Phone Control via Wi-Fi Module (both iOS and Android)
  This charger can be controlled and operated by smart phones via Wi-Fi module (optional part SK-600075).

Specifications:

• Weight: 1240g
• LiPo/LiFe/Lilon/LiHV Battery Cell Count: 1-8S
• DC Input Voltage: 11-30V
• Charge Circuit Power: 1000W
• Charge Current: Max. 40.0A
• Balance Port Charge Current: 10-500mA
• Discharge Circuit Power: 80W
• Discharge Current: 0.1-8.0A
• Regenerative Discharge Current: 0.1-40.0A
• Current Drain for Balancing: Max. 800mA
• NiMH/NiCd Battery Cell Count: 1-20S
• Trickle Charging Current: 50mA-300mA & OFF
• Pb Battery: 2-24V
